ARC-9216S

3U 16Bay 12Gb MiniSAS Hardware RAID Storage

Single or Dual Redundant RAID Controller



Enterprise solutions that don't break the bank. The CineRAID ARC-9216S is a high performance 16bay 12Gb MiniSAS Rack featuring single-upgradable or dual-active (active-active) hardware RAID controllers, designed with the latest 12Gb SAS 3.0 infrastructure. The optional Dual Active-Active controller architecture doubles the available host bandwidth ensuring maximum utilization and throughput. Fail-over protection, If one controller fails, the other controller can transparently take over. Performance and scalability driven, each controller is powered by a dual core RAID-on-Chip (ROC) 1.2Ghz  processor for powerful and proven RAID data storage performance. The high density 16bay chassis supports single or multiple RAID array/s of up to 160 terabytes and fully scalable up to 256 drives by simply daisy-chaining additional expansion storage units for when you need more storage.

Also available in 12 and 24bay solutions.



Key Applications

High Performance Computing, Post Production Editing in 4K and 8K, Big Data Analytics, Forensics Storage and Telecommunications Applications.







\









Specifications

  • Host Interface:

    • Dual 12Gb SAS/MiniSAS HD (SFF-8644) Channel (Per Controller)

  • Expansion Interface:

    • 12Gb HD MiniSAS (SFF-8644) Port

    • Expansion up to 256 HDDs with additional JBOD units

  • Drive Channel Per Enclosure:

    • Up to 16 HDD or SSD with full hot-swap capability

    • Drive trays support both 3.5" and 2.5" drives

    • Supports up to 10TB HDDs

    • Note: Dual Controller requires the use of SAS HDDs

  • Cable-less Hot-Swap Design

  • Single or Dual Redundant Hardware RAID Controllers

    • Dual Controllers provide fault tolerance, increased connectivity and performance

    • Active-Passive and Active-Active Controller Support

  • RAID Features:

    • RAID 0, 1, 3, 5, 6, 10(1E), 30, 50, 60, Single Disk or JBOD

    • Automatic drive failover, detection and rebuild using multiple Global, Dedicated or Enclosure Hot-Spare Drives

    • Multiple RAID 0 and RAID 10(1E) Support (RAID 00 and RAID 100)

    • Multiple pair SSD/HDD disk clone function

    • SSD automatic monitor clone support

    • High performance Areca RAID 60 controller w/ 2GB cache and advanced functionality, up to 128 volumes with access filtering

    • Multi-Path & Load-Balancing Support

  • Monitors/Notifications:

    • Disk activity/failure LED indicators

    • Fan and PSU failure and monitoring

    • SMTP support for email notifications

    • SNMP support for remote manager

    • Enclosure management ready (SES, I2C and SGPIO)

    • User-friendly Web GUI, backup text interface via serial connection

  • Spare trays, PSUs, backplane, and controller modules available.

  • Optional flash-based, maintenance-free cache backup

  • Built-In multiple host connections allow use as shared storage for clusters, expandable with SAS Switch

  • Shared storage support for VMware and Hyper-V for high availability cluster

  •

  • Fans

    • Dual 80mm speed adjustable fans up to 140 CFM total

  • Power Supply

    • Dual 595W Hot-Swap, N+1 Redundant with PFC

    • Supports 100-240VAC input at 47 and 63Hz frequency

  • Environment

    • Temperature : 0 to 40 C operating / -40 to 60 non-operation

    • Relative Humidity : Operating 10% to 80% (non-condensing) / Storage 5% to 95% (non-condensing)

  • Rackmount rails included (21" to 35.5")

  • Dimensions: 19.9" (L) x 17.5" (W) x 5.2" (H)

  • Weight: (without drives)

    • Single Controller: 68lbs

    • Dual Controller: 71lbs

  • Warranty:

    • 3 Year Parts & labor limited warranty W/ 1 Year Advance Replacement

    • Optional 2 Year Extended warranty (5 Year Total)

    • 1 Year BBM - Battery Backup Module Warranty - If Applicable

    • 5 Year Enterprise Hard Drive Warranty - If Applicable

  • Lifetime phone and email support.

  • Data Sheet :

Pricing





Model: ARC-9216SS (Single Controller)

64TB Solution : $8,499

96TB Solution : $10,999

128TB Solution : $12,999

160TB Solution : $15,999



Battery Backup Unit (Add-On) : $199

4TB Spare Hot-Swap Drive : $349

6TB Spare Hot-Swap Drive : $499

8TB Spare Hot-Swap Drive : $599

10TB Spare Hot-Swap Drive : $699



Model: ARC-9216SD (Dual Controller)

64TB Solution : $8,499

96TB Solution : $10,999

128TB Solution : $12,999

160TB Solution : $15,999
