6Bay USB 3.1 Gen2 Type-C Hardware RAID
ARC-8050U3-6 RAID enclosure offers a truly innovative USB 3.1(10.0Gbps) host interface solution for SOHO group professionals who work at home and or in the office. Using USB 3.1 to PCIe bridge and Areca existing ARC-8050T3-6 industry-proven hardware RAID controller, this RAID storage delivers the performance enhancement of USB 3.1 at the best of cost/performance value. With the much faster speed than ordinary USB 3.0 based storage, ARC-8050U3-6 is an alternative RAID storage for SOHO group professionals who need an affordable storage at home and or in the office. The advancement of 10Gbps USB3.1 connectivity allows the RAID storage to transfer end-to-end 10Gbps storage speed and fully backward compatible with USB 3.0/2.0 interconnection. ARC-8050U3-6 is OS independent, with no additional software or driver installation required, and also used on any Thunderbolt™ 3 USB-C port. |
|
|
|
Adapter Architecture | |||||
Dual Core RAID-on-Chip (ROC) 1.2 GHz processor | |||||
On-board 2GB DDR3-1866 ECC SDRAM | |||||
Support 6 internal 12Gb/s SAS ports | |||||
Write-through or write-back cache support | |||||
Redundant flash image for adapter availability | |||||
Battery Backup Module ready (Optional) | |||||
RAID Features | |||||
RAID level 0, 1, 10(1E), 3, 5, 6, Single Disk or JBOD | |||||
Support up to 1MB stripe size | |||||
Online array roaming | |||||
Online RAID level/stripe size migration | |||||
Instant availability and background initialization | |||||
Automatic drive insertion/removal detection and | |||||
rebuilding | |||||
Multiple pairs SSD/HDD disk clone function | |||||
SSD automatic monitor clone support | |||||
SED (self-encrypting drives) function support | |||||
Support native 4K and 512 byte sector devices |
|
||||
Support HDD firmware update | |||||
Support global and dedicated hot spare | |||||
Firmware-level “Hdd Xfer Speed” to measure the | |||||
HDD’s read performance | |||||
Controller-level hardware encryption support | |||||
Monitors/Notification | |||||
Push Buttons and LCD Display Panel for setup and status | |||||
Environment and drive failure indication through LCD, LED and Alarm Buzzer | |||||
Keep silent and adequate air flow and cooling by | |||||
intelligent cooling fan speed controller | |||||
Drive Interface | |||||
Up to 6 x 3.5"/2.5" 12Gb/s SAS or 6Gb/s and | |||||
3Gb/s SAS/SATA HDDs/SSDs | |||||
Host Interface | |||||
1 x 10Gbps USB 3.1 Gen 2 Type-C | |||||
- Supports UASP (USB Attached SCSI Protocol) | |||||
- Backwards compatible with USB 3.0/2.0 | |||||
Dimensions / Weight | |||||
4.84 x 8.45 x 9.11 inches (146 x 255 x 290 mm) |
|
|
|||
13.2 lbs | ARC-8050U3-6 Spec Sheet | ||||
ARC-8050U3-6 Manual | |||||
Warranty | |||||
3 Year Hardware Warranty |
|
||||
Pricing | |||||
ARC-8050U3-6 (Diskless) : $1,199 | |||||
ARC-8050U3-6-24TB : $2,699 | |||||
ARC-8050U3-6-36TB : $2,999 | |||||
ARC-8050U3-6-48TB : $3,499 | |||||
ARC-8050U3-6-60TB : $3,999 | |||||
ARC-8050U3-6-72TB : $4,999 | |||||
